- PLC-5 system family
- Individually fused output channels.
- Each channel can handle a maximum load current of 2A, but the total for the module should not exceed 8A.
- Can power an Allen-Bradley Size 5 motor starter as long as the supply voltage stays above 92V ac.
- Output circuit uses a solid-state triac as its switching device.
- It has a 2500 volts isolation voltage, which protects the backplane logic from line transients on the output circuits and ensures that a failure on one output circuit does not affect another.
- Draws a maximum current of 420mA from the +5V dc output of the power supply connected to the I/O chassis backplane.
- Each output circuit on the 1771-ODD module is designed for a 10mA minimum current.
- Life cycle status: End of life, discontinued December 31, 2016
