Phoenix Contact FL SWITCH 1005N 5-Port Ethernet Switch 10/100 Mbps
Product Basic Information:
- Manufacturer: Phoenix Contact
- Catalog number: FL SWITCH 1005N
- Alternate part numbers: FL SWITCH 1005N, FLSWITCH1005N, 1085039
- Product family/series: Unmanaged Switch 1000
- Product type: Industrial Ethernet switch
- Country of origin: Taiwan
- HS customs code: 851762
Technical Specifications:
- Switch type: Unmanaged Ethernet switch
- Number of ports: 5 RJ45
- Port speed: 10/100 Mbps on all ports
- Transmission standard: 10Base-T and 100Base-TX
- Connection method: RJ45
- Transmission length: 100 m per segment
- Supply voltage DC: 24 VDC nominal
- Supply voltage AC: 24 VAC nominal at 50/60 Hz
- Supply voltage range: 9 to 32 VDC and 18 to 30 VAC at 50/60 Hz
- Maximum current consumption: 110 mA at 9 VDC
- Typical current consumption: 19 mA at 24 VDC
- Maximum power dissipation: 0.99 W at 24 VDC
- Mounting: DIN rail mounting
- Degree of protection: IP30
Product Features:
- Narrow housing design for space saving DIN rail installation
- Automatic data transmission speed detection
- Auto negotiation and autocrossing for easier setup
- QoS prioritized messages
- Enhanced traffic prioritization for automation protocols
- PROFINET PTCP filter for reliable communication on PROFINET networks
- PROFINET Conformance Class A for real time data exchange
- Energy efficient Ethernet in accordance with IEEE 802.3az
- Local diagnostic indicators with LEDs
Product Designed Use:
- Designed for industrial Ethernet communication in automation and control systems
- Used to connect PLCs, HMIs, drives, I/O devices, and other Ethernet enabled industrial equipment
- Suitable for DIN rail mounted control cabinets and machinery panels
- Intended for unmanaged 10/100 Mbps network switching in industrial applications
- For industrial use only
COUNTRY OF ORIGIN INFORMATION IS INCLUDED WHERE AVAILABLE.
* Buyer is responsible for all customs duties, tariffs, brokerage fees, local levies, taxes, and VAT (if applicable).*
KJ CONTROLS LTD IS NOT AN AUTHORIZED DISTRIBUTOR FOR PHOENIX CONTACT
THE ORIGINAL MANUFACTURER'S WARRANTY DOES NOT APPLY
