Rittal Single-Door Wall-Mounted Enclosure
- Part Number: 8017529
- Model number: WM161206NC
- Lifecycle status: ACTIVE
Technical Specifications:
- Material: Door and Housing are made of Carbon steel
- Surface finish: Housing and door are dipcoat primed, powder-coated on the outside, textured paint. The mounting plate is zinc-plated.
- Dimensions: Width: 300 mm (11.8"), Height: 400 mm (15.7"), Depth: 150 mm (5.91")
- Dimensions of mounting plate (W x H): 254 mm x 375 mm (10" x 14.8")
- Material thickness: Door, enclosure, and mounting plate are 1.5 mm (0.06")
- Weight per packaging unit: 9 kg (19.8 lb.)
- NEMA rating: 1, 3R, 4, and 12
Product Features:
- The WM series ensures NEMA protection through a secure locking system, foamed-in-place gasket, and knife-edge sealing surface.
- Features include a cold rolled steel body and door, and a zinc plated mounting panel.
- The door is hinged on the left and the enclosure includes rear wall mounting holes and a quarter turn latch with a slotted head insert.
*Please note that this information is accurate as of the last update and may vary slightly based on the source. For the most accurate and up-to-date information, it’s always a good idea to check directly with the manufacturer or authorized distributor.*
** Buyer is responsible for all customs, brokerage fees, local levies and taxes.**
KJ CONTROLS LTD IS NOT AN AUTHORIZED DISTRIBUTOR FOR RITTAL
The Original Manufacturer's Warranty Does Not Apply
(8A3)
