Schneider Electric BMXAMI0810 Modicon 8-Input Isolated Analog Module
Product Basic Information:
- Manufacturer: Schneider Electric
- Catalog number: BMXAMI0810
- Product family/series: Modicon X80
- Product type: Isolated analog input module
- Input level: High level
- Analogue input number: 8
- Country of origin: France
- HS customs code: 853890
Technical Specifications:
- Electrical connection: 28 ways, 1 connector
- Connection type: Removable terminal block
- Isolation between channels: Isolated
- Analogue input type: Current +/- 20 mA, 0 to 20 mA, 4 to 20 mA
- Voltage input type: +/- 10 V, +/- 5 V, 0 to 10 V, 0 to 5 V, 1 to 5 V
- Analog to digital conversion: 16 bits
- Analogue input resolution: 15 bits plus sign
- Input impedance: 10 MOhm in voltage mode
- Internal conversion resistor: 250 Ohm with 3.6 to 50 Ohm internal protective resistor in current mode
- Filter type: First order digital filtering
- Fast read cycle time: 1 ms plus 1 ms x number of channels used
- Isolation voltage: 300 V DC between channels, 1400 V DC between channels and ground, 1400 V DC between channels and bus
- Current consumption: 150 mA at 3.3 V DC, 45 mA at 24 V DC
- Status indication: 1 green RUN LED, 1 green LED per channel, 1 red ERR LED, 1 red I O LED
- Operating temperature: 0 C to 60 C
- IP degree of protection: IP20
- Protective treatment: Conformal coating
Product Features:
- 8 isolated high level analog inputs for current and voltage signal acquisition
- Supports multiple configurable analog input ranges per channel
- High speed analog acquisition for monitoring and control applications
- Channel to channel isolation with additional isolation to ground and bus
- First order digital filtering for stable signal processing
- Conformal coated design for industrial panel environments
- Front LED indication for RUN, channel diagnostics, ERR, and I O status
Product Designed Use:
- Designed for analog signal acquisition in Modicon X80 PLC and PAC systems
- Used with sensors and transmitters for industrial monitoring, measurement, and continuous process control
- Suitable for automation panels requiring isolated high level current and voltage inputs
